VPA-120 Power Amplifier 120W

SKU: 3005010235 Category: Analog PA Amplifiers

120 W power amplifier in a 19" rack cabinet
100 V and 8 ohm output
Dual inputs with priority switching
Temperature controlled, forced back-to-front ventilation
115/230 VAC mains and 24 VDC battery backup
Pilot tone line monitoring
24 VDC / 800 mA power output for external equipment
Chime signal with on/off switch

The VPA power amplifier is specially designed for marine use. The amplifier has to be installed in 19" rack and occupies 3 HU with addition of a 1 HU ventilation grid.

The amplifier is protected against overload and short circuits. A temperature controlled fan ensure high reliability at high output level and low ventilation noise at lower output levels.

The amplifier operates on 115 or 230 VAC mains with option for automatic switching to 24 VDC battery backup in case of power failure. The amplifier is supervised by a pilot tone to continuously check the signal path, and a fault will be reported by an indicator in front combined with a closing contact for external fault warning.

The amplifier has a built in selectable chime generator activated by a priority switch to give an alert signal in front of a message.
