New top model for ISDN connections or All IP
The
IP3011 replaces the IP3010 and has 1 PRI interface to the trunk and also has 30
conference channels.
•
Successor of the IP3010
•
Recommended for “all in one box” – PBX and UC installations up to 500
users
• 30
voice channels (1 PRI)
• 30
conference channels possible
innovaphone
IP3011 VoIP-PBX and gateway for one ISDN PRI interface plus reverse proxy and
SBC functionalities
Firmware
Device operated with Version 12 or higher
Housing
Size: 210 x 134 x 32 mm one height unit (HU) for 19” systems Weight:
1050 g
Interfaces
1 x PRI-interface (S2M): for connection of ISDN-PRI-trunk line, use on E1 or T1
lines, RJ-45 (modular Jack 8P8C), TE or NT mode operation 2 x Gigabit Ethernet:
1000-BASE-T (auto negotiation), RJ-45 (modular Jack 8P8C) & bdquo; Power
over Ethernet & ldquo; according to IEEE 802.3af, Class 3 Energy Efficient
according to IEEE 802.3az
internal
slot for mSATA SSD Power consumption up to 2.5W compatible to JEDEC MO-300
standard, dimension 50,8 x 29,85 mm
Hardware
Power supply: Power over Ethernet according to IEEE 802.3af, Class 3
800
MHz CPU, 2 GB RAM, 32 MB Flash, 1 GB Flash Disk (NAND)
Operation
temperature: 0 C to +45 C Humidity: 10% to 90% (not condensed) Storage
temperature: -10 C to +70 C
Digital
Signal Processor (DSP) for up to 30 voice/audio conference channels Seven
channels for the innovaphone fax server using T.38 or via G.711. In case of
G.711, each fax transmission consumes 2 DSP channels.
Voice
Codecs G.711 A-law / µ-law, G.723.1 (53), G.729A and Opus-NB incl.
VAD (Voice Activity Detection), CNG (Comfort Noise Generation) Dynamic Jitter
Buffering Echo Compensation according to G.168 Modem support innovaphone
PBX Platform for up to 500 PBX Users (all-in-one) [edit]Generic Features
generic features innovaphone gateways.
|
